Product Name: 12kg railroad light steel rail tracks
Material: Q235/55Q
Length: 5m, 5.5m, 6m.
Application: Factory, Coal, Factory,etc.
| Light Rail YB222-63 | |||||||
| Size | Dimension(mm) | Theoreticalweigt (kg/m) | Length (m/pc) | Material | |||
| Head | Heiht | Bottom | Web | ||||
| GB6kg | 25.4 | 50.8 | 50.8 | 4.76 | 5.98 | 6-12 | Q235 |
| GB9kg | 32.1 | 63.5 | 63.5 | 5.9 | 8.94 | 6-12 | Q235 |
| GB12kg | 38.1 | 69.85 | 69.85 | 7.54 | 12.2 | 6-12 | 55Q/Q235 |
| GB15kg | 42.86 | 79.37 | 79.37 | 8.33 | 15.2 | 6-12 | 55Q/Q235 |
| GB22KG | 50.8 | 93.66 | 93.66 | 10.72 | 22.3 | 6-12 | 55Q/Q235 |
| GB30KG | 60.33 | 107.95 | 107.95 | 12.3 | 30.1 | 6-12 | 55Q/Q235 |
