LZG-31 lithium battery rail drill is suitable for drilling rails below 75kg / m.The rail clamping device has self-locking function.
LZG-31 lithium battery rail drill is suitable for drilling rails below 75kg / m.The rail clamping device has self-locking function.It has the characteristics of accurate positioning and high drilling accuracy.Hollow bit is used to realize the function of automatic water supply during drilling.It is an indispensable tool for railway maintenance, emergency repair, construction engineering and electrical department maintenance.
Engine model | Kw/rpm | 1.2/400 |
Rated voltage | V | 36 |
No-load speed | r/ min | ≥480 (for track communication) |
| r/ min | 300r/min (for track maintenance) |
Bore diameter | mm | Φ9.8 ~ 19.8mm (choose≥480r / min) |
| mm | Φ20~36mm(choose≥300r/min) |
Drilling time | S | :≤ 40 |
Machine weight | Kg | 18.2 |
Drilling stroke | mm | ≥40 |
Overall size | mm | 530*270*410 |
