The electric rail cutting machine is suitable for cutting 43/m75/m rail, and the quality of the cutting section meets the requirements of the railway industry standard.
The electric rail cutting machine is suitable for cutting 43/m75/m rail, and the quality of the cutting section meets the requirements of the railway industry standard. It is an indispensable tool for line overhaul, maintenance and emergency repair operations of railway works department. It has the characteristics of fast cutting speed, high utilization rate of flake grinding wheel, high cutting section quality, simple operation, easy movement, safe use and wide application range.
Name | railway electric cutting machine | |
Rails Applicable | 43kg/m-75kg/m | |
Internal Combustion Engine | Model | Honda Gasoline Engine GX200 |
Rate of Power | 4.8kw | |
Rotate Speed | 3600r/min | |
Sheet Wheel(Main Shaft) | Rotate Speed | 3030r/min |
Specification | Φ400×Φ32×4 | |
Cutting Time | 60kg/m | ≤120S |
Use Frequency of Sheet Wheel | 50kg/m | ≥4 |
60kg/m | ≥3 | |
Weight | 39.5KG | |
